Certified Load-Rated Hardware

Rigging Tools & Hardware

Engineered for heavy industrial hoisting, maritime towing, overhead lifting, and structural tensioning. Our certified rigging hardware, drop-forged shackles, high-tensile wire rope slings, and lifting clamps deliver maximum working load limits (WLL) and safety factors.

View Product Gallery
Quality Standards & Load Verification

Rigging Hardware Standards & Capacity Matrix

Every rigging component and lifting accessory supplied by Nemat Engineering conforms to stringent international proof test requirements, featuring stamped working load limits (WLL) and test certificates.

Technical details of rigging hardware, applicable safety codes, and load ratings
Hardware Category Standard / Specification Capacity / Size Range Design Factor & Grade Typical Industrial Application
Shackles (Bow & D-Type) US Fed. Spec. RR-C-271 / EN 13889 0.5 Ton to 120 Ton WLL 6:1 Safety Factor (Grade 6 & 8) Marine towing, crane hooks, structural rigging
Wire Rope Slings & Clips IS 2266 / ASME B30.9 / EN 13414 6 mm to 64 mm Diameter 5:1 Factor (EIPS / EEIPS Core) Heavy dockyards, construction hoisting, mining
Chain Slings & Hoists EN 818-4 / ASME B30.16 / IS 2760 1 Ton to 50 Ton Capacity Grade 80 & Grade 100 Alloy Steel High-temperature foundries, heavy shop-floor lifts
Turnbuckles & Tensioners ASTM F1145 / US Fed. Spec. FF-T-791b 1/4" to 2-1/2" Thread Dia. 5:1 Factor (Drop Forged Carbon Steel) Guy wire tensioning, mast lashing, pipe bracing
Plate & Beam Clamps EN 13155 / ASME B30.20 1 Ton to 30 Ton Working Load Safety Lock & Hardened Alloy Jaws Vertical and horizontal structural plate handling
Synthetic Slings (Web / Round) EN 1492-1 / EN 1492-2 / ASME B30.9 1 Ton to 40 Ton Capacity 7:1 Safety Factor (100% PES) Machined components, coated pipes, fragile cargo
Why Choose Nemat Rigging Hardware

Certified Safety Factors & Proof-Tested Reliability

Designed to maintain metallurgical integrity and dimensional fidelity under dynamic shock loads, harsh offshore environments, and repetitive hoisting cycles.

5:1 & 7:1 Safety Design Engineered with certified safety margins, ensuring all lifting points and tensioning tackle withstand sudden dynamic load shifts without elongation.
100% Proof Load Verified Individual batch testing up to 2x Working Load Limit (WLL) paired with Magnetic Particle Inspection (MPI) to guarantee absence of forging flaws.
Complete MTC Traceability Every shackle, hook, master link, and sling assembly is stamped with batch heat numbers linked directly to verified manufacturer test certificates.

Single-Source Heavy Lifting & Rigging Supplies

Nemat Engineering simplifies critical industrial procurement by supplying complete rigging configurations—combining custom wire rope slings, forged shackles, Grade 80 chain assemblies, and manual lever pullers in a single coordinated shipment. Every delivery is fully certified and tagged ready for immediate job-site commissioning.

Have a Custom Rigging or Lifting Requirement?

Submit your required Working Load Limits (WLL), sling configurations, and hardware specifications for an immediate commercial proposal.

Request a Rigging RFQ
